MX 24

Rating:
90 % of 100
$500.00
Assembly Options Professionally assembled by your local dealer, or DIY the assembly - its up to you!
Financing Available Buy Now, Pay Later with Klarna. We’ve partnered with Klarna to offer flexible payment options to pay over time.
30 Day Returns Our love your ride guarantee – if you’re not 100% happy with your bike, we’re not happy either. Click here for more details
Frame Warranty Covered for at least 5 years! Check out the details to see if your bike qualifies for longer.
Brakes
Linear
Tire Size
24 x 1.75"
Frame material
Aluminum

Ready to snap the gate for the first time? Returning to the sport? Made with an aluminum frame and integrated head tube, the Redline MX24 is lightweight and easy to maneuver. The MX24 features a high-quality 3-piece crank set, integrated headset, Pivotal Race saddle, and 24 inch wheels. The Redline MX24 is top of class for value and quality, and best of all, it’s race-ready out of the box.

  • Frame 6061 Alloy w/Integrated Headtube
  • Fork RL Race Hi-Ten w/ Tapered legs
  • Headset Integrated 1 1/8"
  • Cranks Race Chromo 175mm 3pc Cranks
  • Sprocket 41t, Alloy
  • Bottom Bracket Euro
  • Cogset 18t
  • Chain KMC Z410
  • Front Hub Redline Aluminum
  • Rear Hub RL Aluminum Flip-Flop
  • Spokes 14g Steel
  • Rims Alloy Race 24 x 1.75, 36h
  • Tires Vee Speedster 24 X 1.75"
  • Brake Levers Tektro
  • Pedals RL Aluminum 9/16" Platform
  • Handlebar RL Race, 5.5" Rise / 12° Back / 1° Up
  • Grips Redline Hex Expert w/plugs
  • Stem RL Hollow Point Aluminum 1 1/8" threadless
  • Seat Pivotal Race
  • Seatpost Pivotal 26.8
  • Brakes Tektro BX310 Linear
  • Product ID 4713

* Specifications are subject to change without notice

Frame Size 24"
Rider Height -
Bike Top Tube Length 21.8 "
Bike Head Angle 74.0 °
Bike Seat Angle 70.0 °
Bike Chain Stay Length 15.1 "
Bike Bb Height 12.0 "
Bike Stem Length 55.0 mm
Bike Handlebar Width 28.0 "
Bike Crank Length 175.0 mm
Rider height chart
FEET
CM
3'11'' 4' 4'1'' 4'2'' 4'3'' 4'4'' 4'5'' 4'6'' 4'7'' 4'8'' 4'9'' 4'10'' 4'11'' 5' 5'1'' 5'2'' 5'3'' 5'4'' 5'5'' 5'6'' 5'7'' 5'8'' 5'9'' 5'10'' 5'11'' 6' 6'1'' 6'2'' 6'3'' 6'4'' FEET
CM
119.0 122.0 124.0 127.0 130.0 132.0 135.0 137.0 140.0 142.0 145.0 147.0 150.0 152.0 155.0 157.0 160.0 163.0 165.0 168.0 170.0 173.0 175.0 178.0 180.0 183.0 185.0 188.0 191.0 193.0
RL275,PL26,SQB 26
MONOCOG XL
MONOCOG LG
MONOCOG MD
MONOCOG SM
Asset 24
ASSET/MXII/RL20II
RANDOM/RECON/ROMP
RIVAL
PROLINE PRO XXL
PROLINE PRO 24/MX-24
PROLINE PRO XL
PROLINE PRO/MX-20
MX EXPERT XL / ROAM
MX EXPERT
MX JUNIOR
MX MINI
